True to it’s name, OMEGA represents the family of High Speed Machining Centers, which are an ultimate combination of Productivity and Precision. They are specially crafted to meet the dynamically rising global market demands across various industry segments from Electronics to Automotive to Aerospace to Defence.
True to it’s name, OMEGA represents the family of High Speed Machining Centers, which are an ultimate combination of Productivity and Precision. They are specially crafted to meet the dynamically rising global market demands across various industry segments from Electronics to Automotive to Aerospace to Defence.
High productive machine with rapid rates up to 54m/min, minimum tool change time of 1.3 sec & spindle speeds up to 24,000rpm.
Wide range of products in BBT30 and BBT40 (HSK A63) variants with axes strokes going upto 1000x600mm, making the Omega machines suitable for many Electronics & EV parts.
Omega Penta brings in 5 axis continuous machining capability to the Omega range.
Omega Duo, with it’s innovative configuration of independent Z axis, helps achieve unmatched productivity combined with savings in floor space and energy consumption.
| OMEGA PENTA | ||||
| Description | 30S | 30L | 40S | 40L |
| Traverse | ||||
| X Axis (mm) | 500 | 650 | 500 | 650 |
| Y Axis (mm) | 560 | 600 | 560 | 600 |
| Z Axis (mm) | 380 | 380 | 500 | 400 |
| Spindle face to table top - Min./Max. (mm) | 100/480 | 0/380 | 40/540 | 0/400 |
| Height Block | No | No | No | No |
| Spindle | ||||
| Taper | BBT 30 | BBT 30 | BBT 40 | BBT 40 |
| Spindle Power (kW) Cont /int | 8.2/12 | 8.2/12 | 5.5/7.5/11 | 5.5/7.5/11 |
| Torque (Nm) | 26/38 | 26/38 | 35.5/44/60 | 35.5/44/60 |
| Maximum Speed (opt) (RPM) | 20000 | 20000 | 12000 | 12000 |
| Table | ||||
| Rotary Table Size (C-Axis) mm | Dia. 260 | Dia. 400 | Dia. 260 | Dia. 400 |
| Load carrying capacity (Kg) | 60 | 100 | 60 | 100 |
| A-axis speed (RPM) | 200 | 60 | 200 | 60 |
| C-axis speed (RPM) | 200 | 200 | 200 | 200 |
| A-axis rotation angle Degrees | +/-110 | +/-110 | +/-110 | +/-110 |
| Axis | ||||
| X/Y/Z Rapid Traverse (m/min) | 54/54/54 | 48/48/48 | 54/54/54 | 48/48/48 |
| X/Y/Z Max cutting feed rate (mm/min) | 20000 | 20000 | 20000 | 20000 |
| Tool Magazine | ||||
| Type | Direct Pickup | Direct Pickup | Direct Pickup | Direct Pickup |
| Max Pockets of Tool Magazine | 21 | 21 | 24 | 24 |
| Max tool Diameter (mm) | 80 | 80 | 80 (125) | 80 (125) |
| Max tool weight (kg) | 3 | 3 | 6 | 6 |
| Max Tool length (mm) | 200 | 200 | 250 | 250 |
| Chip to Chip time (Seconds) | 2.4 | 2.4 | 3.5 | 3.5 |
| Accessories | ||||
| Coolant gun and air gun | Yes | Yes | Yes | Yes |
| 3 Tier lamp | Yes | Yes | Yes | Yes |
| Lamella cover for Z axis | Yes | Yes | Yes | Yes |
| Auto front door | Option | Option | Option | Option |
| Coolant through Spindle (Optional) | 16 Bar | 16 Bar | 16 Bar | 16 Bar |
| CNC System | ||||
| CNC System | BFW-SYNTEC | BFW-SYNTEC | BFW-SYNTEC | BFW-SYNTEC |
